W25Q80BW
8.
ELECTRICAL CHARACTERISTICS
8.1 Absolute Maximum Ratings (1)
PARAMETERS
Supply Voltage
Voltage Applied to Any Pin
Transient Voltage on any Pin
SYMBOL
VCC
V IO
V IOT
CONDITIONS
Relative to Ground
<20nS Transient
RANGE
– 0.6 to VCC+0.4
– 0.6 to VCC+0.4
– 2.0V to VCC+2.0V
UNIT
V
V
V
Relative to Ground
Storage Temperature
T STG
– 65 to +150
° C
Lead Temperature
T LEAD
See Note
(2)
° C
Electrostatic Discharge Voltage
V ESD
Human Body Model (3)
– 2000 to +2000
V
Notes:
1. This device has been designed and tested for the specified operation ranges. Proper operation outside
of these levels is not guaranteed. Exposure to absolute maximum ratings may affect device reliability.
Exposure beyond absolute maximum ratings may cause permanent damage.
2. Compliant with JEDEC Standard J-STD-20C for small body Sn-Pb or Pb-free (Green) assembly and
the European directive on restrictions on hazardous substances (RoHS) 2002/95/EU.
3. JEDEC Std JESD22-A114A (C1=100pF, R1=1500 ohms, R2=500 ohms).
8.2 Operating Ranges
PARAMETER
SYMBOL
CONDITIONS
MIN
SPEC
MAX
UNIT
F R = 80MHz
Supply Voltage (1)
VCC
f R
= 50MHz (03h &
1.65
1.95
V
Continuous Read Mode)
Ambient Temperature,
Operating
T A
Industrial
– 40
+85
°C
Note:
1. VCC voltage during Read can operate across the min and max range but should not exceed ±10% of
the programming (erase/write) voltage.
- 58 -
